Service Manual
Product spec and feature
2-32
Samsung Electronics
2.2.4.3 Loading Paper
Load the print media you use for the majority of your print jobs in the tray.
The tray can hold a maximum of 150 sheets of 75 g/ (20 lb bond) plain paper.
1. Grasp the paper input tray and pull it toward you to
open. Pinch the rear guide and pull it out to extend
the tray.
2. Prepare a stack of paper for loading by flexing or
fanning them back and forth. Straighten the edges
on a level surface.
3. Load paper with the print side facing up. Make sure
that all four corners are flat in the tray.
4. Pinch the rear guide to adjust for the paper length
and pinch the side guide and slide it to the left flush
against the paper.
5. If necessary, close the paper cover to keep the
paper loaded in the tray from dust.
