Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-8
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.3-0 JC96-05120A ELA UNIT-FRAME 1 SA A
5.3-1 JC61-01152A FRAME-M-BASE 1 SNA A
5.3-2 JC97-02218A MEA UNIT-PLATE KNOCK_UP 1 SA A
5.3-2-1 JC61-01158A PLATE-M-KNOCK_UP 1 SA A
5.3-2-2 JC66-00720A SHAFT-P-CORE 1 SA A
5.3-2-3 JC72-01004A PMO-IDLE KNOCK UP MP 2 SA A
5.3-2-4 JC74-00011A MPR-PAD KNOCK UP MP 1 SA A
5.3-3 JC61-01258A SPRING ETC-TORSION DEVE_L 1 SA A
5.3-4 JC61-01259A SPRING ETC-TORSION DEVE_R 1 SA A
5.3-5 JC96-05116A ELA UNIT-DRIVE 1 SA A
5.3-5-1 JC61-01153A BRACKET-P-GEAR 1 SNA A
5.3-5-2 JC61-01154A BRACKET-P-MOTOR 1 SNA A
5.3-5-3 JC66-00804A GEAR-RDCN 139/83 1 SA A
5.3-5-4 JC31-00112A MOTOR STEP 1 SA A
5.3-6 JC97-02218A MEA UNIT-PLATE KNOCK_UP 1 SA A
5.3-7 JC70-00500C ADJUST-CASSETTE_R 1 SA A
5.3-8 JC70-00499C ADJUST-CASSETTE_L 1 SA A
5.3-9 JG66-40003A GEAR-PINION 1 SA A
5.3-10 JC61-00836A FOOT-FRONT 2 SA A
5.3-11 JC66-00805A GEAR-RDCN 113/83 1 SA A
5.3-12 JC66-00806A GEAR-OPC DR 76/38/29 1 SA A
5.3-13 JC66-00807A GEAR-FUSER DR 63/35 1 SA A
5.3-14 JC66-00808A GEAR-FEED DR 41 1 SA A
5.3-15 JC66-00822A LEVER-M-ACTUATOR_EMPTY 1 SA A
5.3-16 JB61-00076A SPRING ETC-TORSION DOC (CC2-F) 1 SA A
5.3-17 JC63-00622A GROUND-P-OPC 1 SA A
5.3-18 JC61-00025A SPRING ETC-CS-CHARGE APOLLO 2 SNA A
5.3-19 JC67-00110A CAP-M-MOTOR 1 SNA A
Frame Parts List(ML-1640)
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
