Samsung ML-1645

Service Manual
ExplodedView and Parts list
5-10
Samsung Electronics
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.4-0 JC96-05121A ELA HOU-FUSER 1 SA A 1640/110V
5.4-0 JC96-05122A ELA HOU-FUSER 1 SA A ML-1640/XSA
5.4-0 JC96-05124A ELA HOU-FUSER 1 SA A 2240/110V
5.4-0 JC96-05125A ELA HOU-FUSER 1 SA A 2240/220V
5.4-1 JC61-01162A FRAME-P-FUSER 1 SNA A
5.4-2 JC63-00615A COVER-M_FUSER 1 SNA D
5.4-3 JC61-01177A HOLDER-M-EXIT R 2 SA A
5.4-4 JC66-00810A GEAR-EXIT_DRV17 1 SA B
5.4-5 JC61-01172A HOLDER-M-EXIT F/DOWN 3 SNA A
5.4-6 6107-001168 SPRING-CS 2 SA D
5.4-7 JC66-10901A BUSH-PRESSURE R 2 SA A
5.4-8 JC61-00595A GUIDE-M-INPUT 1 SNA A
5.4-9 JC66-00600A ROLLER-PRESSURE 1 SA A
5.4-10 JC66-00601B ROLLER-HEAT 1 SA A
5.4-11 JC66-00564A GEAR-FUSER Z37 1 SA D
5.4-12 JC61-00589A BUSH-M-HR L 1 SA A
5.4-13 JC61-00590A BUSH-M-HR R 1 SA A
5.4-14 4713-001202 LAMP-HALOGEN 1 SA A 1640/220V
5.4-14 4713-001203 LAMP-HALOGEN 1 SA A 1640/110V
5.4-14 4713-001211 LAMP-HALOGEN 1 SA A 2240/110V
5.4-14 4713-001212 LAMP-HALOGEN 1 SA D 2240/220V
5.4-15 JC66-00824A ROLLER-M-EXIT MAIN 3 SA D
5.4-16 JC66-00830A ROLLER-M-EXIT FR 3 SA D
5.4-17 6107-001163 SPRING-CS 3 SA D
5.4-18 1404-001451 THERMISTOR-NTC ASSY 1 SA A
5.4-19 4712-001032 THERMOSTAT 1 SA A
5.4-20 JC39-00404A CBF HARNESS-FUSER JOINT 1 SA A
5.4-21 JC39-00403A CBF HARNESS-FUSER(110V) 1 SA A 110V
5.4-21 JC39-00403B CBF HARNESS-FUSER(220V) 1 SA A 220V
5.4-22 JC61-00064A SPRING ETC-CLAW 4 SA A
5.4-23 JC61-02580A GUIDE-CLAW 4 SA A
5.4-24 JC66-00801A GEAR-EXIT_DR38/25 1 SNA D
5.4-25 6031-001051 WASHER-PLAIN 1 SNA A
5.4-26 JC63-00637A COVER-M-FUSER-DUMMY 1 SNA D
5.4-27 JC63-00639A COVER-M-LAMP-L 1 SNA D
5.4-28 JC63-00638A COVER-M-LAMP-R 1 SNA D
5.4-29 6044-000001 RING-CS 1 SNA B
5.4-30 JC66-00826A ROLLER-EXIT F/DOWN 1 SA A
5.4-31 JC67-00085A CAP-M-THERMO 1 SNA A
Fuser Parts List
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
