Samsung ML-1645

ExplodedView and Parts list
Drawer# SEC_CODE DESCRIPTION QT’Y Service Grade Remark
5.6-0 JC97-02239G MEA UNIT-MP TRAY 1 SA B
5.6-1 JC61-01263F PLATE-MP 1 SA B
5.6-2 JC70-00514E ADJUST-MP L 1 SA B
5.6-3 JC70-00515E ADJUST-MP R 1 SA B
5.6-4 JG66-40003A GEAR-PINION 1 SA B
5.6-5 JC63-00711A SHEET-MP 1 SA B
MP Tray Parts List
*SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
*Grade : Parts Class”A,B,C,D,E”
