5-17
Samsung Electronics
Disassembly and Reassembly
Service Manual
7. Remove the Feed Gear1, as shown below. 8. Remove the Feed Roller and Feed Roller1, as
shown below.
Feed Gear1
Feed Roller1
Feed Roller
