6-12
6. Material List
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
R530/R730
Level Code Assembled EA Description Spec. Service
......3 0505-001883 Q517 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q6 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q8 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-002340 Q19 1 FET-SILICON FDMS9620S,N,30V,16A/18A,0.021/0.013ohm,2.5W,Power56
......3 0505-002340 Q21 1 FET-SILICON FDMS9620S,N,30V,16A/18A,0.021/0.013ohm,2.5W,Power56
......3 0505-002386 Q518 1 FET-SILICON AO3415AL,P,-20V,-4A,0.045ohm,1.5W,SOT-23
......3 0505-002510 Q1 1 FET-SILICON AON6716L,N,30V,85A,0.0028ohm,2.3W,SO-8(PowerPAK)
......3 0505-002510 Q2 1 FET-SILICON AON6716L,N,30V,85A,0.0028ohm,2.3W,SO-8(PowerPAK)
......3 0505-002595 Q24 1 FET-SILICON AP2607GY-HF,P,-20V,-4A,0.052ohm,2W,SOT-26
......3 0601-002846 LED1 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0801-002628 U1 1 IC-CMOS LOGIC 7SZ08,2-INPUT AND GATE,SC-70,5P,49MIL,SINGLE,TP,CMOS,1.8/
5.5V,0V,-40to+85,150mW,0V,20uA,10uA,-
......3 0801-002998 U2 1 IC-CMOS LOGIC 74AHCT1G125,Single buffer,SC-70,5P,2x1.25mm,SINGLE,TP,3-
STATE,4.5/5.5V,0.44V,-40
......3 0801-002998 U3 1 IC-CMOS LOGIC 74AHCT1G125,Single buffer,SC-70,5P,2x1.25mm,SINGLE,TP,3-
STATE,4.5/5.5V,0.44V,-40
......3 0904-002378 U10 1 IC-I/O CONTROLLER AF82801IBM,mBGA,676P,31x31mm,100MHz,TR,PLASTIC,3.3V,4.3W,
0to+113C,ICH9-M(BASE)
......3 0904-002453 U13 1 IC-BUS CONTROLLER AU6336,QFN,28P,5x5mm,48MHz,TR,Plastic,3.3V,0to+85C,SDHC
......3 0904-002484 U7 1 IC-DRAM CONTROLLER EB88CTGM,FCBGA,1329P,34x34mm,533MHz,TR,PLASTIC,1.05V,12W,
0to+105C,GM45
......3 1006-001427 U6 1 IC-BUS TRANSCEIVER PS8101,QFN,48P,7x7mm,TR,PLASTIC,3.3V,0to+70C,916mW,2.4V,HDM
I level shifter
......3 1203-005867 U4 1 IC-BATTERY BQ24751BRHDR,QFN,28P,5x5x0.9mm,PLASTIC,8/18.048V,2.26W,-
40to+155C,-,3.267/3.333V,TP
......3 1203-006049 U15 1 IC-PWM CONTROLLER APW7141QAITRG,QFN,14P,3.5x3.5mm,-,-0.75V to 5.5V,80W,-
40to+85C,-,0.75V,TP
......3 1203-006056 U12 1 IC-POSI.ADJUST REG. APL5930 KAI-TRG,SOP,8P,4.9x3.9mm,PLASTIC,0.8/3.3,3W,-
40to+85C,3A,0.8,TR,-
......3 1203-006083 U14 1 IC-POSI.ADJUST REG. APL5336KAITRG,SOP-8P,8P,5x4mm,PLASTIC,-.03to7V,80,-
40to+85C,1.5A,-.03to7V,TP,0.9V
......3 1205-003156 U5 1 IC-CLOCK GENERATOR SLG8SP513,QFN,64P,9x9mm,PLASTIC,3.465V,0.825W,0to+70C,-,clock
generator
......3 1205-003769 U9 1 IC-CODEC ALC269Q-GR,QFN,48P,7x7mm,PLASTIC,5.25V,-,0to+70C,TR,-
......3 1404-001089 TH3 1 THERMISTOR-PTC 0.21ohm,-,-,6Vac,40A,2.2A,TP
......3 1404-001152 TH1 1 THERMISTOR-NTC 10KOHM,5%,3380K,1MW/C,TP
......3 1404-001152 TH2 1 THERMISTOR-NTC 10KOHM,5%,3380K,1MW/C,TP
......3 2007-000043 R833 1 R-CHIP 1Kohm,1%,1/10W,TP,1608
......3 2007-000070 R15 1 R-CHIP 0ohm,5%,1/10W,TP,1608
......3 2007-000070 R90 1 R-CHIP 0ohm,5%,1/10W,TP,1608
......3 2007-000141 R11 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R12 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R155 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R24 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R30 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R35 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R36 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R64 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R65 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000141 R68 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000171 R17 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R18 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R31 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R32 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R33 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R34 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000173 R158 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R165 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R166 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000309 R103 1 R-CHIP 10ohm,5%,1/10W,TP,1608
......3 2007-000503 R203 1 R-CHIP 2.2ohm,5%,1/10W,TP,1608
......3 2007-000882 R40 1 R-CHIP 4.7ohm,5%,1/10W,TP,1608
......3 2007-000939 R181 1 R-CHIP 47Kohm,1%,1/10W,TP,1608
......3 2007-001139 R89 1 R-CHIP 7.5Kohm,1%,1/10W,TP,1608
......3 2007-001313 R169 1 R-CHIP 330ohm,5%,1/16W,TP,1005
