Part List : NP-R528-DA03HU
Ver. Location Part Number Part Name & Specification Q'ty SA/SNA Parent Part
0001 I0009 BA43-00207A BATTERY;3UR18650Y-2-SDN-26,BONN,Li-ion,2 1 SA NP-R528-DA03HU
0001 I0009 BA43-00208A BATTERY;P32R04-13-H01,BONN,Li-ion,2P3S,4 1 SA NP-R528-DA03HU
0001 I0013 BA59-02690A MODULE-CAMERA;SCB-0350M,MC020M-0AA1DU939 1 SA BA96-04509A
0001 K0001 BA75-02370A UNIT-HOUSING_LCD-BACK;BREMEN-15L,SEC,IMR 1 SA BA96-04509A
0001 K0002 BA75-02376A UNIT-HOUSING_LCD-FRONT;BREMEN-15L,SEC,PC 1 SA BA96-04509A
0001 K0100 BA81-04180B RUBBER-FRONT;LYON,TPU,D5.0*H2.1mm,HS90,G 6 SA BA96-04509A
0001 K0104 BA81-04858A RUBBER-FRONT;LYON,SILICON RUBBER,GRAY,W2 2 SA BA75-02376A
0001 K0201 BA68-05528C LABEL-FRONT_R528;BREMEN-15L,SEC,PC,T0.3, 1 SA NP-R528-DA03HU
0001 K1001 BA39-00929A CBF HARNESS-LCD+CAMERA;BREMEN(15),WIRE,- 1 SA BA96-04509A
0001 K1001 BA39-00932A CBF HARNESS-LCD+CAMERA;BREMEN(15),WIRE,- 1 SA BA96-04509A
0001 K1001 BA39-00951A CBF HARNESS-LCD+CAMERA;BREMEN(15),WIRE,- 1 SA BA96-04509A
0001 K1006 BA81-09035A PROTECTOR-LCD_BACK;BREMEN-15L,PET XY53,W 1 SA NP-R528-DA03HU
0001 K2001 BA42-00216A ANTENNA-WLAN;81.EHD15.004,Winchester,2.4 1 SA BA75-02370A
0001 K2002 BA42-00236A ANTENNA-WLAN;WDAN-M1MM1001-DF,Miami,2.4- 1 SA BA75-02370A
0001 K3001 BA61-01242A HINGE-L;BREMEN-15L,SUS,T1.5,W40.7,L28.2m 1 SA BA96-04509A
0001 K3001 BA81-06418A HINGE-L;BONN,SUS,T1.5,W40.7*L28.2*T1.4mm 1 SA BA96-04509A
0001 K3001 BA81-06488A HINGE-L;BONN,SUS,T1.5,W40.7*L28.2*T1.4mm 1 SA BA96-04509A
0001 K3002 BA61-01243A HINGE-R;BREMEN-15L,SUS,T1.5,W40.7,L28.2m 1 SA BA96-04509A
0001 K3002 BA81-06419A HINGE-R;BONN,SUS,T1.5,W37.0*L28.0*H22.8m 1 SA BA96-04509A
0001 K3002 BA81-06489A HINGE-R;BONN,SUS,T1.5,W37.0*L28.0*H22.8m 1 SA BA96-04509A
0001 K4001 BA81-06390A BRACKET-LCD_L;BONN,SECC,T0.8,W233.4*L11. 1 SA BA96-04509A
0001 K4002 BA81-06391A BRACKET-LCD_R;BONN,SECC,T0.8,W233.4*L11. 1 SA BA96-04509A
0001 L1004 BA68-20039A LABEL-PPID_E;BLADE,-,PET,-,W50.8,L9mm,wh 2 SA BA99-16006A
0001 L1004 BA68-20039A LABEL-PPID_E;BLADE,-,PET,-,W50.8,L9mm,wh 1 SA NP-R528-DA03HU
0001 M0001 BA92-06338A ASSY MOTHER BD-TOP;BREMEN-UL,PGA,DDR3,GL 1 SA NP-R528-DA03HU
0001 M0008 BA92-05996A ASSY BOARD-USB_SUB;BREMEN-M,USB_POWER SW 1 SA NP-R528-DA03HU
0001 M1004 2203-001683 C-CER,CHIP;0.068nF,5%,50V,NP0,1608 1 SA BA92-06338D
0001 M1004 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,1608 8 SA BA92-06338C
0001 M1004 2203-006000 C-CER,CHIP;1nF,10%,3000V,X7R,TP,4520 1 SA BA92-06338D
0001 M1009 3711-000456 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 SA BA92-06338D
0001 M1010 3710-002788 SOCKET-INTERFACE;7+15P,1R,1.27mm,SMD-A,A 1 SA BA92-06338D
0001 M1022 0904-002453 IC-BUS CONTROLLER;AU6336,QFN,28P,5x5mm,4 1 SA BA92-06338D
0001 M1022 1006-001427 IC-BUS TRANSCEIVER;PS8101,QFN,48P,7x7mm, 1 SA BA92-06338D
0001 M1025 1203-006083 IC-POSI.ADJUST REG.;APL5336KAITRG,SOP-8P 2 SA BA92-06338D
0001 M1028 3722-002925 JACK-USB;4P/2C,AUF,BLK,ANGLE-OFFSET,A,- 1 SA BA92-06338C
0001 M1028 3722-002997 JACK-DC POWER;3P,5.6PI,AUF,BLK 1 SA BA92-06338C
0001 M1028 3722-003036 JACK-MODULAR;8P/8C,STANDARD,N,dip,-,AU,1 1 SA BA92-06338C
0001 M1033 4301-000108 BATTERY-LI;3V,220mAH,CR2032,20x3.2mm,NO, 1 SC BA92-06338A
0001 M1033 4301-001070 BATTERY-LI;3V,210mAH,CR2032,20x3.2mm,NO, 1 SA BA92-06338A
0001 M1049 1205-003904 IC-ETHERNET CONTROLLER;88E8040-A0-NNB2C0 1 SA BA92-06338C
0001 M1057 1203-005536 IC-PWM CONTROLLER;TPS51117RGYR,QFN,14P,3 1 SA BA92-06338D
0001 M1057 1203-005735 IC-PWM CONTROLLER;RT8205AGQW,QFN,24P,4x4 1 SA BA92-06338C
0001 M1057 1203-005849 IC-PWM CONTROLLER;ISL6255AHRZ-T,QFN,28P, 1 SA BA92-06338D
0001 M1057 1203-005864 IC-PWM CONTROLLER;TPS51620RHAR,QFN,40P,6 1 SA BA92-06338C
0001 M1059 1205-003913 IC-SWITCH;G546A4P1UF,SOP-8,8P,4.9x6x1.55 1 SA BA92-06338C
0001 M2001 BA75-01937A UNIT-BRACKET_CPU;PALAU,SEC,SPCC,W50*L40* 1 SA BA92-06338A
0001 M3004 BA81-08475A FAN-CPU;BREMEN-15UL,KSB0705HA-9J58,Plast 1 SA BA62-00498B
0001 M3004 BA81-08475B FAN-CPU;BREMEN-15UL,0F81G0000M-1,Plastic 1 SA BA62-00498B
0001 M3005 BA62-00498A HEAT SINK-CPU;BREMEN-15UL,AL,14,136,155, 1 SA NP-R528-DA03HU
