Samsung NP-R538E User Manual (FreeDos) Service Manual

- This Document can not be used without Samsung's authorization -
Part List : NP-R528-DA03HU
Ver. Location Part Number Part Name & Specification Q'ty SA/SNA Parent Part
0001 M3005 BA62-00498B HEAT SINK-CPU;BREMEN-15UL,AL,14,136,155, 1 SA NP-R528-DA03HU
0001 M9999 0403-001047 DIODE-ZENER;BZX84C12L,5%,225mW,SOT-23,TP 1 SA BA92-06338D
0001 M9999 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 2 SA BA92-06338D
0001 M9999 0801-002628 IC-CMOS LOGIC;7SZ08,2-INPUT AND GATE,SC- 1 SA BA92-06338D
0001 M9999 0904-002378 IC-I/O CONTROLLER;AF82801IBM,mBGA,676P,3 1 SA BA92-06338D
0001 M9999 0904-002489 IC-DRAM CONTROLLER;AC82GL40,FCBGA,1329P, 1 SA BA92-06338D
0001 M9999 1205-002596 IC-SWITCH;TPS2062,SOIC,8P,5x6x1.65mm,PLA 1 SA BA92-06338C
0001 M9999 1205-003156 IC-CLOCK GENERATOR;SLG8SP513,QFN,64P,9x9 1 SA BA92-06338D
0001 M9999 1205-003159 IC-CLOCK GENERATOR;IDTCV179CNLG,MLF,64P, 1 SA BA92-06338D
0001 M9999 1205-003533 IC-CLOCK GENERATOR;SL28541BQCT,QFN,64P,9 1 SA BA92-06338D
0001 M9999 1205-003769 IC-CODEC;ALC269Q-GR,QFN,48P,7x7mm,PLASTI 1 SA BA92-06338D
0001 M9999 1209-001887 IC-SENSOR;EMC2112-BP-TR,QFN,20P,4x4mm,PL 1 SA BA92-06338C
0001 M9999 2007-007274 R-CHIP;27.4Kohm,1%,1/10W,TP,1608 1 SA BA92-06338D
0001 M9999 2203-001201 C-CER,CHIP;0.007nF,0.5pF,50V,NP0,TP,1005 2 SA BA92-06338C
0001 M9999 2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,TP,1005 1 SA BA92-06338D
0001 M9999 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 62 SA BA92-06338D
0001 M9999 2203-006090 C-CER,CHIP;10000nF,10%,6.3V,X5R,TP,2012 19 SA BA92-06338D
0001 M9999 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,1608 5 SA BA92-06338D
0001 M9999 3003-001158 MIC-CONDENSOR;4.5V,-,-42dB,2.2kOhm 1 SA BA92-06338C
0001 M9999 3404-001311 SWITCH-TACT;12VDC,50mA,100gf,6.0x6.0x5.0 1 SA BA92-06338D
0001 M9999 3404-001382 SWITCH-TACT;12V,50mA,100gf,6.0x6.0x5.0mm 1 SA BA92-06338D
0001 M9999 3701-001515 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AU 1 SA BA92-06338C
0001 M9999 3701-001597 CONNECTOR-HDMI;19P,2R,FEMALE,ANGLE,Au 1 SA BA92-06338C
0001 M9999 3708-002166 CONNECTOR-FPC/FFC/PIC;25P,1.0mm,SMD-A,AU 1 SA BA92-06338C
0001 M9999 3708-002402 CONNECTOR-FPC/FFC/PIC;6P,1.0mm,SMD-A,SnB 1 SA BA92-06338C
0001 M9999 3709-001492 CONNECTOR-CARD SLOT;9P,2.5mm,SMD-A,AU,2 1 SA BA92-06338D
0001 M9999 3709-001559 CONNECTOR-CARD EDGE;204P,0.6mm,SMD-A,Au, 1 SA BA92-06338D
0001 M9999 3709-001560 CONNECTOR-CARD EDGE;204P,0.6mm,SMD-A,Au, 1 SA BA92-06338D
0001 M9999 3710-002634 SOCKET-INTERFACE;13P,1R,1mm,ANGLE,AU,BLK 1 SA BA92-06338C
0001 M9999 3711-007011 HEADER-BATTERY;NOWALL,7P,1R,2.5mm,BATTER 1 SA BA92-06338C
0001 M9999 3722-002588 JACK-PHONE;6P,AU,BLK,ANGLE 2 SA BA92-06338C
0001 M9999 3722-002767 JACK-USB;4P/1C,AU,BLK,ANGLE,A 1 SA BA92-06338C
0001 R0006 BA75-01944B UNIT-BRACKET_HDD;BREMEN-15L,SEC,SECC,W71 1 SA BA97-02997A
0001 T0001 BA75-02371A UNIT-HOUSING_TOP;BREMEN-15L,SESC,ASSY,W3 1 SA NP-R528-DA03HU
0001 T0002 BA81-08523A UNIT-HOUSING_TOP_SVC;BREMEN-15L,SEC,PC/A 1 SA BA75-02371A
0001 T0005 BA68-03765A LABEL-LOGO_PENTIUM;NP ALL,-,PC,T0.1,W0.8 1 SA NP-R528-DA03HU
0001 T0006 BA68-05763A LABEL-ZAIGEN;BREMEN,ENG(DOS),PET+PP,-,W9 1 SA NP-R528-DA03HU
0001 T0101 BA59-02411A BOARD-TOUCHPAD;SAMOA,TM-01020-004,C/M,PC 1 SA BA75-02371A
0001 T0300 BA39-00845A CBF HARNESS-USB_SUB-BOARD;CANNES,Wire,UL 1 SA NP-R528-DA03HU
0001 T0300 BA39-00846A CBF HARNESS-USB_SUB-BOARD;CANNES,Wire,UL 1 SA NP-R528-DA03HU
0001 T0302 BA41-01096A FFC-TOUCHPAD;BONN,1.0,Film,6P,T0.3mm,92* 1 SA BA75-02371A
0001 T0407 BA81-08515A INSULATOR-TOUCHPAD;BREMEN-15L,PC,W72.9*L 1 SA BA75-02371A
0001 T2000 BA96-03966A ASSY SPEAKER;BONN,-,160/450,RED/BLK,WHT/ 1 SA BA75-02371A
0001 W2004 0203-001869 TAPE-KAPTONE;K-CJ01,T0.06,W10,L33000mm,Y 0 SA BA92-06338A
0001 W2004 0203-001869 TAPE-KAPTONE;K-CJ01,T0.06,W10,L33000mm,Y 0 SA NP-R528-DA03HU
0001 W2004 2007-009768 R-CHIP;10.7Kohm,1%,1/16W,TP,1005 1 SA BA92-06338C
0001 W2004 3708-002582 CONNECTOR-FPC/FFC/PIC;12P,0.5mm,SMD-A,Au 1 SA BA92-06338D
0001 W2004 BA68-04737A LABEL-ENERGY_BLANK;R410,-,ART PAPER,T0.0 1 SA NP-R528-DA03HU
0001 W2004 BA81-05632A SCREW-MACHINE;SANTORINI,SESC,SWRCH18A 3+ 2 SA BA97-02997A
