Samsung NX30 User Manual

Specifications 131
X15 Plus Model
* Please refer to the product catalog or consult your product provider for availability when purchasing optional
accessories for this system.
Item Specification Remarks
CPU Intel Pentium M 1.3~1.7GHz / Dothan
Cache memory 1MB(Pentium M)/2MB(Dothan)
Main memory 128/256/512/1024 MB DDR SDRAM, 2 DDR socket Max 2GB
Main Chipset Odem+ / ICH4M
Hard disk drive (HDD) 2.5’’, UltraDMA 100, S.M.A.R.T 9.5mmH
CD Drive CD-ROM drive, CD-RW drive, DVD-ROM drive,
CD-RW/DVD-ROM Combo drive, DVD-Multi Drive
Optional
Graphics Nvidia GeForce FX Go 5200, Memory : 64MB
1024x768 pixels (XGA) / 1400x1050 pixels (SXGA+) / 1600x1200
pixels (UXGA)
Sound Chipset : Cirrus Logic CS4202(AC97 CODEC)
Network Interface Modem: SENS LT56ADW
Wired LAN: 10/100 Base T Ethernet
Wireless: 802.11b or 802.11b/g
Optional
PCMCIA Slot Type I and II Compatible
Memory Stick Slot Supports up to 128MB
Ports IEEE1394 (4 pin), USB 2.0 (x2), Microphone, Headphone, S/PDIF,
Modem (RJ-11), Wired LAN (RJ-45), Monitor, TV Out (S-Video)
Options Li-Ion smart battery, USB port replicator, car adapter, external
battery charger, ear-set
Dimensions (mm) 327.8 x 277.7 x 26.7 W x D x H
LCD Panel Size 15" XGA / SXGA+ / UXGA TFT LCD Optional
Weight 2.34 Kg (including 6cell battery)
Battery Li-Ion Smart Battery
Operation
Environment
Temperature (storage) : -5 ~ 40°C (operation) : 10 ~ 32° C
Humidity (storage) : 5% ~ 90% (operation) : 20% ~ 80%
Operation Voltage 100 ~ 240 VAC
Frequency 50 ~ 60 Hz
Input/Output Power 60W
Output Voltage 19.0 VDC

Samsung NX30 Specifications

General

Megapixel	20.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	21.6 MP
Image sensor size	- \
Maximum image resolution	5472 x 3648 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Image stabilizer location	Lens
Still image resolution(s)	5472 x 3648, 3888 x 2592, 2976 x1984, 1728x 1152, 2736 x 1824, 5472 x 3080, 3712 x 2088, 2944 x 1656, 1920 x 1080, 3648 x 3648, 2640 x 2640, 2000 x 2000, 1024 x 1024, 5472 x 3648, 2688 x 1512, 1920 x 1080
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Samsung NX
Maximum aperture number	5.6
Minimum aperture number	3.5
Focus	TTL
Normal focusing range	11 m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	-
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Video recording	Yes
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 810, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1037000 pixels
Magnification	0.96 x
USB version	2.0
Scene modes	Portrait, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Manual, Tungsten
Shooting modes	Aperture priority, Auto, Program, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	- s
Power source type	Battery
Battery type	BP1410
Battery voltage	7.6 V
Battery capacity	1410 mAh
Battery life (max)	3 h
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	127 mm
Width	41.7 mm
Height	95.5 mm
Weight	375 g
