22 Users Manual
Reading the Status Indicators
Location of status indicators may differ depending on the model. (p3)
LED Name Function
Num Lock Turns on when the numeric keypad is activated.
Caps Lock Turns on when the user has set the option for typing letters in upper case.
Scroll Lock Turns on when it is set to scroll the screen up and down while the cursor
position does not change in some applications.
HDD Blinks when the hard disk drive is operating.
Battery Turns green - when the battery is fully charged, or when the battery is not
installed.
Turns amber - when the battery is being charged.
Blinks - when the battery is not properly installed.
Power Turns on - when the computer is turned on.
Blinks - when the computer is in Standby mode.
