16 Users Manual
Using Special Function Keys
The function key activates special functions when it is pressed in combination with
another keys. Table 2 shows the special key combinations.
<Fn> Key
Combinations
Key Name Key Function
<Esc/Rest> Rest Puts the computer into suspended mode. To escape suspended mode,
press the power button. (p87)
<F2/ > Gauge You can check the power supply and the battery charge.
<F4/ LCD/CRT> LCD/CRT Switches the display between the LCD and external display device
when an external display device is connected. (p84)
<F6/ Mute> Mute Turns the audio output on and off.
<F7/ S/PDIF> S/PDIF Turns the S/PDIF function on and off.
<F11/Num Lock> Number Lock Enables the numeric keypad. (p15)
<F12/Scroll> Scroll Lock Scrolls the screen up and down while the cursor position does not
change in some applications.
</> Brightness Up Makes the LCD screen brighter.
</> Brightness Down Makes the LCD screen dimmer.
</> Volume Down Decreases the audio volume.
</> Volume Up Increases the audio volume.
When operating on
AC power
When operating
on battery power
Power Supply Status
Remaining Battery Charge Level (%)

Samsung NX30 Specifications

General

Megapixel	20.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	21.6 MP
Image sensor size	- \
Maximum image resolution	5472 x 3648 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Image stabilizer location	Lens
Still image resolution(s)	5472 x 3648, 3888 x 2592, 2976 x1984, 1728x 1152, 2736 x 1824, 5472 x 3080, 3712 x 2088, 2944 x 1656, 1920 x 1080, 3648 x 3648, 2640 x 2640, 2000 x 2000, 1024 x 1024, 5472 x 3648, 2688 x 1512, 1920 x 1080
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Samsung NX
Maximum aperture number	5.6
Minimum aperture number	3.5
Focus	TTL
Normal focusing range	11 m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	-
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
Video recording	Yes
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 810, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1037000 pixels
Magnification	0.96 x
USB version	2.0
Scene modes	Portrait, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Manual, Tungsten
Shooting modes	Aperture priority, Auto, Program, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	- s
Power source type	Battery
Battery type	BP1410
Battery voltage	7.6 V
Battery capacity	1410 mAh
Battery life (max)	3 h
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	127 mm
Width	41.7 mm
Height	95.5 mm
Weight	375 g
