Samsung OfficeServ 7030 - Page 19

iDCS 64B AOM (See Figure 2–13)
• 64 programmable keys with red lights
• A maximum of 2 can be assigned to any keyset to provide addi-
tional programmable keys
• The maximum number of iDCS 64B AOM per system is limited
by the available DLI ports.
• Requires a DM port
• Available in dark gray
iDCS 14B STRIP (See Figure 2–14)
• 14 programmable keys with red lights
• A maximum of one can be added to any 28D or 18D keyset to provide
additional programmable keys
• Does not require a DM port
• Available in dark gray
Note: The KDB-D/KDB-S/F modules are not supported on the iDCS and DS keysets on the OfficeServ 7030 system.
2.8
FIGURE 2-13
FIGURE 2-14
