PART 3. SPECIFICATIONS
3.1 ELECTRICAL SPECIFICATIONS
The specifications of the power I/O are shown in the table below.
3.2 DIMENSIONS
The OfficeServ 7030 consists of a single cabinet as shown in Figure 3-1.
3.1
3.1a I/O VOLTAGE of the PSU
PSU (OfficeServ 7030)
Input Voltage
100-120 VAC ~ 2A 50/60 Hz
DC -48V ~ 1.5A (Battery Backup)
Output Voltage DC -54V, 0.5A (Max 15W)
DC +5V, 3.0A (Max 15W)
DC +12V, 1.8A (Max 21.6W)
Maximum Power Consumption/PSU 63.6W
HEIGHT WIDTH DEPTH
OfficeServ 7030 Cabinet 2.875” 12.56” 14.31”
FIGURE 3-1
3.3 ENVIRONMENTAL LIMITS
OPERATING TEMPERATURE 32—113 °F / 0—45 °C
STORAGE TEMPERATURE 14—122 °F / --10—50 °C
HUMIDITY 10%—90% Non-Condensing
BTU
MAXIMUM LOAD 70% LOAD
Wattage BTU/h BTU/min Wattage BTU/h BTU/min
77.1W 263.1 4.39 53.97W 184.2 3.07
