SAFETY STANDARD & FILE NUMBERS
UL 508 (File No. E56140. E108658)
C22.2 No.0, No.14 (File No. LR35579))
VDE 0435, 0631, 0700
Please be noted that UL/CSA rating may
differ from the Standard ratings.
Please request when the approval markings
are required on the cover.
■
ODERING INFORMATION
■
COILDATA CHART
VSB-12STB
Type
Enclosure
B : Flux Free Type
C : Washable Type (with tape)
Contact Arangement
M : 1 From A (SPST-NO)
T : 1 From C (SPDT)
Coil Sensitivity
Ni : Standard Type
S : High Sensitive Type
Nominal Voltage
Note) 1. Actual making omits the hyphen (-) of (
󳢬 )
5. VSB Relay
Relay type contact ratings
Nominal
coil Voltage
VSB 3 to 100VDC
1/3HP
16A
125VAC/250VAC
30VDC/250VAC, Resistive
Pilot duty C 150
VSB - 3 ( ) ( )
VSB - 5 ( ) ( )
VSB - 6 ( ) ( )
VSB - 9 ( ) ( )
VSB - 12 ( ) ( )
VSB - 14 ( ) ( )
VSB - 18 ( ) ( )
VSB - 24 ( ) ( )
VSB - 36 ( ) ( )
VSB - 48 ( ) ( )
VSB - 60 ( ) ( )
VSB - 100 ( ) ( )
VSB - 3S ( ) ( )
VSB - 5S ( ) ( )
VSB - 6S ( ) ( )
VSB - 9S ( ) ( )
VSB - 12S ( ) ( )
VSB - 14S ( ) ( )
VSB - 18S ( ) ( )
VSB - 24S ( ) ( )
VSB - 36S ( ) ( )
VSB - 48S ( ) ( )
VSB - 60S ( ) ( )
VSB - 100S ( ) ( )
3
5
6
9
12
14
18
24
36
48
60
100
3
5
6
9
12
14
18
24
36
48
60
100
36
50
115
200
280
460
820
1,850
3,300
5,100
13,400
17
47
68
155
270
370
610
1,100
2,450
4,400
6,800
18,860
2.1
3.5
3.5
6.3
8.4
9.8
12.6
16.8
25.2
33.6
42.0
70.0
2.1
3.5
4.2
6.3
8.4
9.8
12.6
16.8
25.2
33.6
42.0
70.0
0.3
0.5
0.5
0.9
1.2
1.4
1.8
2.4
3.6
4.8
6.0
10.0
0.3
0.5
0.6
0.9
1.2
1.4
1.8
2.4
3.6
4.8
6.0
10.0
0.72
0.70
0.72
0.70
0.72
0.70
0.70
0.70
0.70
0.70
0.70
0.75
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
12.5
Standard Type
High Sensitive Type
ORDERING CODE
Coil Nominal
Voltage
V DC
Coil Resistance
Ω±10%
(at 20℃)
Must Operate
Voltage
V DC (at 20℃)
Must Release
Voltage
V DC (at 20℃)
Coil Nominal
Power
W (at 20℃)
(❊)
