OPTION SET-VALUE SELECT MODE
(Power Cool LED Lamp Off)
● When the Display Panel converts to the Option Setting mode, the Display will be changed to the Option #
Select Mode or the Option Set
1) For example, if you want to
shift the standard temp of th
e Fridge compartment by -2℃, follow the
below. This function is to change the default temperature and when the default temperature of the Fridge
compartment is 2℃ and the default setting is lowered by -2℃ with the Option function, the default
temperature will be controlled at 0℃. That is, wh
en changing temperature options, the
will operate at 0℃ internally even if it
shows 2℃ on the display panel. Therefore,
controlled by -2℃ lower than the set temperature on the display panel.
2) After changing into the Option mode, “0"s on both of the Fridge and Freezer compartments lights up on
the display panel. (when units being shipped out, the unit will be shipped out with "0" set on the Fridge
compartments. However, for the purpose
of quality improvement during mass production, the
are on (Setting the Option #), press the Fridge Button and select the LED LAMP which equals to the Set-
OFF, "3℃" LED ON). Then, its default temperature drops by -2℃.
Basically, when units being shipped out, all the
data in the Option function are
cleared. That is, the Default
settings are “0”. However, for the
purpose of quality improvement during mass production,
values may change. Therefore, be sure to
check quality information, such as SVC bulletins.
