* Self-Diagnosis Error Description
When the Failure Condition occurs, the Compressor will immediately stop if the Compressor is running
and there will be a 5 minute
standby. During the 5 minute standby, RPM signals will be ignored. That is,
even though the Inverter PBA receives the RPM
signals, the Compressor does not work.
second and there is 2 second off at the end of each cycle.
1. Short between COMP U,V, and W phase (CN102)
2. Short among IC3 Pins (No. #1~24)
3. Drop the IPM operating Voltage under DC 13.5V
check the COMP, cycle, etc.
1. Open the COMP wire (CN102)
2. Bad condition of resistor R1(ex. Bad soldering)
check the COMP, cycle, etc.
1. Operating the locked rotor COMP within 5 second.
2. Operating the COMP under 1000 RPM more than
3. Occur the huge change of input voltage in a
check the COMP, cycle, etc.
resistor R514 (DC link resistor)
1. Increase the input voltage
2. Short resistor among R511, R512 and R513
LED blinking frequency dependi
ng on protecting functions If
the same blinking, After 5
LED blinking frequency depending on
protecting functions(Inverter PBA)
