Samsung S3C8275X - Pin Circuit Type H-10 (P2.0)

S3C8275X/F8275X/C8278X/F8278X/C8274X/F8274X PRODUCT OVERVIEW
1-11
V DD
Data
Output
Disable 1
Resistor
Enable
V DD
Circuit
Type H-4
P-CH
N-CH
Pull-Up
Resistor
I/O
Open-Drain
SEG
Alternative
Function
BLDEN
BLD Select
To BLD
Figure 1-10. Pin Circuit Type H-10 (P2.0)
