Samsung S3C8275X - IPH Instruction Pointer (High Byte); IPL Instruction Pointer (Low Byte)

S3C8275X/F8275X/C8278X/F8278X/C8274X/F8274X CONTROL REGISTER
4-17
IPH — Instruction Pointer (High Byte) DAH Set 1
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
Reset Value
x x x x x x x x
Read/Write
R/W R/W R/W R/W R/W R/W R/W R/W
Addressing Mode
Register addressing mode only
.7–.0 Instruction Pointer Address (High Byte)
The high-byte instruction pointer value is the upper eight bits of the 16-bit instruction
pointer address (IP15–IP8). The lower byte of the IP address is located in the IPL
register (DBH).
IPL
— Instruction Pointer (Low Byte) DBH Set 1
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
Reset Value
x x x x x x x x
Read/Write
R/W R/W R/W R/W R/W R/W R/W R/W
Addressing Mode
Register addressing mode only
.7–.0 Instruction Pointer Address (Low Byte)
The low-byte instruction pointer value is the lower eight bits of the 16-bit instruction
pointer address (IP7–IP0). The upper byte of the IP address is located in the IPH
register (DAH).
