Samsung S3C8275X - FLAGS System Flags Register

CONTROL REGISTERS S3C8275X/F8275X/C8278X/F8278X/C8274X/F8274X
4-12
FLAGS — System Flags Register D5H Set 1
Bit Identifier .7 .6 .5 .4 .3 .2 .1 .0
Reset Value
x x x x x x 0 0
Read/Write
R/W R/W R/W R/W R/W R/W R R/W
Addressing Mode
Register addressing mode only
.7 Carry Flag (C)
0 Operation does not generate a carry or borrow condition
1 Operation generates a carry-out or borrow into high-order bit 7
.6 Zero Flag (Z)
0 Operation result is a non-zero value
1 Operation result is zero
.5 Sign Flag (S)
0 Operation generates a positive number (MSB = "0")
1 Operation generates a negative number (MSB = "1")
.4 Overflow Flag (V)
0
Operation result is ≤ +127 or ≥ –128
1 Operation result is > +127 or < –128
.3 Decimal Adjust Flag (D)
0 Add operation completed
1 Subtraction operation completed
.2 Half-Carry Flag (H)
0 No carry-out of bit 3 or no borrow into bit 3 by addition or subtraction
1 Addition generated carry-out of bit 3 or subtraction generated borrow into bit 3
.1 Fast Interrupt Status Flag (FIS)
0 Interrupt return (IRET) in progress (when read)
1 Fast interrupt service routine in progress (when read)
.0 Bank Address Selection Flag (BA)
0 Bank 0 is selected
1 Bank 1 is selected
