IMR — Interrupt Mask Register DDH Set 1
Bit Identifier .7 .6
.5 .4 .3 .2 .1 .0
Reset Value
x x
x x x x x x
Read/Write
R/W R/W
R/W R/W R/W R/W R/W R/W
Addressing Mode
Register addressing mode only
.7 Interrupt Level 7 (IRQ7) Enable Bit; External Interrupts P1.4–1.7
0 Disable (mask)
1 Enable (unmask)
.6 Interrupt Level 6 (IRQ6) Enable Bit; External Interrupts P1.3
0 Disable (mask)
1 Enable (unmask)
.5 Interrupt Level 5 (IRQ5) Enable Bit; External Interrupt P0.2
0 Disable (mask)
1 Enable (unmask)
.4 Interrupt Level 4 (IRQ4) Enable Bit; External Interrupt P0.1
0 Disable (mask)
1 Enable (unmask)
.3 Interrupt Level 3 (IRQ3) Enable Bit; External Interrupt P0.0
0 Disable (mask)
1 Enable (unmask)
.2 Interrupt Level 2 (IRQ2) Enable Bit; Watch Timer Overflow
0 Disable (mask)
1 Enable (unmask)
.1 Interrupt Level 1 (IRQ1) Enable Bit; SIO Interrupt
0 Disable (mask)
1 Enable (unmask)
.0 Interrupt Level 0 (IRQ0) Enable Bit; Timer 1/A Match, Timer B Match
0 Disable (mask)
1 Enable (unmask)
NOTE: When an interrupt level is masked, any interrupt requests that may be issued are not recognized by the CPU.
