Alignment and adjustment
5-8 Samsung Electronics
SAC20 SCA23
MODE OSD DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
E6 FF FF FF FF NOT USED
E7 FF FF FF FF NOT USED
E8 FF FF FF FF NOT USED
ED FF FF FF FF NOT USED
EE FF FF FF FF NOT USED
EF FF FF FF FF NOT USED
F0 FF FF FF FF NOT USED
E9 FF FF FF FF NOT USED
EA FF FF FF FF NOT USED
EB FF FF FF FF NOT USED
EC FF FF FF FF NOT USED
F1 FF FF FF FF NOT USED
F2 FF FF FF FF NOT USED
F3 FF FF FF FF NOT USED
SCA20 SCA23 SCA25
MODE OSD DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
CD HALLA 70 70 70 70 70 70 HALL AUTO ADJUSTMENT
CE IRISR D0 D0 D0 D0 D0 D0 IRIS CONTROL RANGE ADJUSTMENT
CF WBA FF FF FF FF FF FF WHITE BALANCE AUTO ADJUSTMENT
D0 LENSA FF FF FF FF FF FF LENS AUTO ADJUSTMENT
D6 Z.CHK 80 80 80 80 80 80 ZOOM VR CENTER AUTO ADJUSTMENT
O3 IRIS1 70 70 70 70 70 70 IRIS LEVEL CONTROL-HIGH BYTE
O5 P.CLK 40 40 40 40 40 40 P.CLK ADJUSTMENT
O7 ADREF OO OO OO OO OO OO A/D REFERENCE CONTROL(SETUP)
O8 S.CLK O8 O8 O8 O8 O8 O8 SOFT CLIP CONTROL
O9 AGC1 18 18 18 18 18 18 AGC CONTROL
OB HAPER 58 58 58 58 58 58 HORIZONTAL APPERTURE GAIN
OC YSEL F8 F8 F8 F8 F8 F8 VERTICAL APPERTURE GAIN
1C CWBR 3D 3D 3D 3D 3D 3D COLOR W/B COEFF. OF Cr SIGNAL
1D CWBB 90 90 90 90 90 90 COLOR W/B COEFF. OF Cb SIGNAL
32 CRGP 38 38 38 38 38 38 INDOOR R-Y POSITIVE GAIN
33 CRGN 38 38 38 38 38 38 INDOOR R-Y NEGATIVE GAIN
34 CHYE O5 O5 O5 O5 O5 O5 INDOOR R-Y POSITIVE HUE
35 CHB O5 O5 O5 O5 O5 O5 INDOOR R-Y NEGATIVE HUE
36 CBGP 1E 1E 1E 1E 1E 1E INDOOR B-Y POSITIVE GAIN
37 CBGN 18 18 18 18 18 18 INDOOR B-Y NEGATIVE GAIN
38 CHGR 18 18 18 18 18 18 INDOOR B-Y POSITIVE HUE
39 PCBHN O8 O8 O8 O8 O8 O8 INDOOR B-Y NEGATIVE HUE
53 ECGAN 80 80 80 80 80 80 CHROMA GAIN CONTROL
54 ESY 83 83 83 83 83 83 Y SET-UP LEVEL CONTROL
55 EWC AE AE AE AE AE AE WHITE CLIP CONTROL
57 EUSC EC EC EC EC EC EC B-Y SIGNAL BURST LEVEL CONTROL
58 EVSC OO OO OO OO OO OO R-Y SIGNAL BURST LEVEL CONTROL
5D XKCON OO OO OO OO OO OO SCK CONTROL
5E MDSEL O1 O1 O1 O1 O1 O1 D/ZOOM MODE SELECTION
5F TGMSE O2 O2 O2 O2 O2 O2 TG MODE SELECTION
65 HRGDL OO OO OO OO OO OO H1/H2/RG DELAY CONTROL
66 SHP.D OO OO OO OO OO OO SHP/SHD DELAY CONTROL
67 ADDL OO OO OO OO OO OO SPO/FECKDELAY CONTROL
71 ROUGP 36 36 36 36 36 36 OUTDOOR R-Y POSITIVE GAIN
72 ROUGN 2C 2C 2C 2C 2C 2C OUTDOOR R-Y NEGATIVE GAIN
73 CHOYE O5 O5 O5 O5 O5 O5 OUTDOOR R-Y POSITIVE HUE
74 CHOB 13 13 13 13 13 13 OUTDOOR R-Y NEGATIVE HUE
75 GOUGP 23 23 23 23 23 23 OUTDOOR B-Y POSITIVE GAIN
76 BOUGN 1B 1B 1B 1B 1B 1B OUTDOOR B-Y NEGATIVE GAIN
77 CHOGR 18 18 18 18 18 18 OUTDOOR B-Y POSITIVE HUE
6. Initial data of camera parts adjustment - CAMERA AF 2nd MICOM (UPD784035GC-818) DATA
