R524 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R525 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R526 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R530 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R531 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R532 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R533 2007-000483 R-CHIP;1ohm,5%,1/10W,DA,TP,2012
R536 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R537 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R538 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R540 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R541 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R542 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R543 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R544 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R545 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R550 2007-000503 R-CHIP;2.2OHM,5%,1/16W,DA,TP,1608
R551 2007-000503 R-CHIP;2.2OHM,5%,1/16W,DA,TP,1608
R552 2007-000503 R-CHIP;2.2OHM,5%,1/16W,DA,TP,1608
R559 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R601 2007-001700 R-CHIP;330Kohm,0.5%,1/16W,DA,TP,1608
R602 2007-001693 R-CHIP;15Kohm,0.5%,1/16W,DA,TP,1608
R603 2007-001700 R-CHIP;330Kohm,0.5%,1/16W,DA,TP,1608
R604 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R605 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R606 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R607 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R608 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R609 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R611 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R612 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R613 2007-000065 R-CHIP;2.2Mohm,5%,1/16W,DA,TP,1608
R614 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R615 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R616 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R617 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R618 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R619 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R620 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R621 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R623 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R624 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R625 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R626 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R627 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R628 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R629 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R630 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R631 2007-000290 R-CHIP;100ohm,5%,1/10W,DA,TP,2012
R632 2007-001644 R-CHIP;10Kohm,0.5%,1/16W,DA,TP,1608
R633 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R634 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R635 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R636 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R637 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R638 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R639 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R640 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R641 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R644 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R646 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R648 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R655 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R656 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R657 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R658 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R659 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R660 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R661 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R662 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R663 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R664 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R665 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R667 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R668 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R669 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R670 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R671 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R672 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R673 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R674 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R675 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R676 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R677 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R678 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R679 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R680 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R683 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R684 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R685 2007-000033 R-CHIP;0ohm,5%,1/8W,DA,TP,3216
R686 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
XT601 2801-001449 CRYSTAL-SMD;32.768KHZ,20PPM,28-AAW,12.5P
XT602 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13
VIDEO BLOCK
C101 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C102 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C103 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C104 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C105 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C106 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C107 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C108 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C109 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C110 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C111 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C112 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C113 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C114 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C115 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C116 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C117 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C118 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C120 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C121 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C122 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C123 2203-001686 C-CERAMIC,CHIP;75PF,5%,50V,CH,TP,1608,1.
C124 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C125 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C126 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C151 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C152 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C153 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C154 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C155 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C156 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C158 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C159 2203-001616 C-CERAMIC,CHIP;270pF,5%,50V,CH,1608,1.6m
C162 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C163 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C164 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C165 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C166 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C167 2203-001568 C-CERAMIC,CHIP;110PF,5%,50V,CH,TP,1608,1
C168 2203-000851 C-CERAMIC,CHIP;39PF,5%,50V,NPO,TP,1608,-
C201 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C202 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C203 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C204 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C205 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C206 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C207 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C208 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m
C209 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C212 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C214 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
Loc.No Part No Desc & Spec Remark Loc.No Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-5
