C215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C216 2404-000166 C-TA,CHIP;2.2uF,20%,10V,-,TP,3216,-
C217 2404-000166 C-TA,CHIP;2.2uF,20%,10V,-,TP,3216,-
C218 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C219 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C220 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C221 2203-000357 C-CERAMIC,CHIP;150pF,5%,50V,NPO,TP,1608,
C223 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C224 2203-000919 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP,
C225 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C226 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C227 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C228 2203-001402 C-CERAMIC,CHIP;220nF,+80-20%,16V
C229 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C230 2402-001008 C-AL,SMD;220uF,20%,4V,-,6.6x6.6x5.4mm,2
C231 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C232 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C233 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C234 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C236 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C237 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C238 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C239 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C241 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C242 2203-001568 C-CERAMIC,CHIP;110PF,5%,50V,CH,TP,1608,1
C243 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C244 2203-000851 C-CERAMIC,CHIP;39PF,5%,50V,NPO,TP,1608,-
C245 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C246 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C247 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C248 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C249 2404-000261 C-TA,CHIP;680nF,20%,20V,-,TP,3216,-
C250 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C251 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C252 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C253 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
C254 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C255 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C256 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C257 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C258 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C259 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C260 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C261 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C262 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C263 2203-001658 C-CERAMIC,CHIP;47pF,5%,50V,CH,1608,1.6mm
C264 2404-000198 C-TA,CHIP;22uF,20%,6.3V,-,TP,3528,-
C265 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C266 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C267 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C269 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C270 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C291 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C301 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C302 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C303 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C304 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C306 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C307 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C308 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C309 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C310 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C315 2203-001618 C-CERAMIC,CHIP;27pF,5%,50V,CH,1608,1.6mm
C316 2203-001588 C-CERAMIC,CHIP;18pF,5%,50V,CH,1608,1.6mm
C318 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C319 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
C320 2203-002220 C-CERAMIC,CHIP;56PF,5%,50V,CH,TP,1608,-
C321 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
C322 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C324 2203-001697 C-CERAMIC,CHIP;82PF,5%,50V,CH,TP,1608,1.
C325 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C326 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C351 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CN101 3708-001243 CONNECTOR-FPC/FC/PIC;11P,1MM,SMD-A,SN
D151 0407-000145 DIODE-ARRAY;DCC010,-80V,100mA,C2-3,SOT-2
D201 0407-000115 DIODE-ARRAY;DAN202U,80V,100mA,CA
D202 0401-000171 DIODE-SWITCHING;MA111,80V,100mA,-,3nS,SM
D203 0407-000102 DIODE-ARRAY;DA204U,20V,100MA,C2-3,SC-70,
IC101 1201-001087 IC-PREAMP;52369,QFP,48P,-,SINGLE,-,PLAST
IC201 AC14-12012G IC;CXA1700R,QFP,-
IC202 1201-001083 IC-AGC AMP;1211,SOP,8P,225MIL,DUAL,5dB,P
IC203 AC14-12015G IC-LINEAR;NJM2249V,SSOP,TAPE
IC302 AC14-12014E IC-CCD;CXL5502N,DIP,-
L101 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L102 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L103 2703-001493 INDUCTOR-SMD;10uH,5%,2.5x2.0x1.8
L151 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L152 2703-000385 INDUCTOR-SMD;330uH,5%,3.2x2.5x2.2mm
L153 2703-000416 INDUCTOR-SMD;100uH,5%,2.5x3.2x2.2mm
L154 2703-000388 INDUCTOR-SMD;470uH,5%,3.2x2.5x2.2mm
L155 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L157 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L158 2703-001493 INDUCTOR-SMD;10uH,5%,2.5x2.0x1.8
L202 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm
L203 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L205 2703-001494 INDUCTOR-SMD;100UH,5%,2.5X2.0X1.8
L206 2703-000385 INDUCTOR-SMD;330uH,5%,3.2x2.5x2.2mm
L207 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm
L209 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L210 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L211 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm
L212 2703-000376 INDUCTOR-SMD;8.2uH,5%,2.5x2x1.8mm
L301 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L302 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L305 2703-001498 INDUCTOR-SMD;4.7UH,5%,2.5X2.0X1.8
L306 2703-000367 INDUCTOR-SMD;33uH,5%,2.5x2x1.8mm
L351 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
Q102 0506-000148 TR-ARRAY;UMT2N,PNP,2,-50V,-40V,-100MA,3
Q151 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q152 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q154 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
Q156 0501-000207 TR-SMALL SIGNAL;2SC3142,NPN,150MW,SOT-23
Q157 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q201 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q206 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
Q207 0506-000151 TR-ARRAY;UMZ1N,NPN/PNP,1,50V,40V,100MA,
Q208 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q209 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q210 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
Q211 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q214 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q215 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
Q216 0504-000110 TR-DIGITAL;DTC114EU,NPN,200mW,10K-10Kohm
Q219 0501-000162 TR-SMALL SIGNAL;2SA1576,PNP,200mW,SC-70,
Q220 0504-000177 TR-DIGITAL;DTC143EUA,NPN,200MW,4.7K-4.7K
Q222 0504-000177 TR-DIGITAL;DTC143EUA,NPN,200MW,4.7K-4.7K
Q223 0504-000105 TR-DIGITAL;DTA114EU,PNP,200MW,10K-10K,SC
Q231 0501-000162 TR-SMALL SIGNAL;2SA1576,PNP,200mW,SC-70,
Q302 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
Q303 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q304 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
Q305 0506-000150 TR-ARRAY;UMX2N,NPN,2,50V,40V,100MA,300M
Q306 0501-000162 TR-SMALL SIGNAL;2SA1576,PNP,200mW,SC-70,
Q352 0506-000146 TR-ARRAY;UMH6N,NPN,2,150MW,UM6,TP,68
Q381 0501-000162 TR-SMALL SIGNAL;2SA1576,PNP,200mW,SC-70,
Q382 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
R000 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R103 2007-000099 R-CHIP;62Kohm,5%,1/16W,DA,TP,1608
R104 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R105 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R106 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R107 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R108 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R110 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R112 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R113 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
7-6
Samsung Electronics
Electrical Parts List
