ENGLISH
68
Specifications
✤ The design and technical specifications may be changed without notice.
System SCL901/L906/L907
Recording system Video: 2 rotary heads Helical scanning FM
Audio: FM monaural system
Video signal NTSC color, EIA standard
Usable cassette Hi8 or 8mm
Tape speed SP: 14.345 mm/sec
Speed mode Record: SP only Playback: SP only
Recording time P6-120: 120 min.
FF or REW time P6-120: approx. 6.5 min.
Image device CCD (Charge Coupled Device)
Optical zoom ratio 22x
Focal length: f 3.6~79.2 mm
F 1.6
Filter diameter 46 mm
Focus system Inner
Macro Auto wide macro
Min. Illumination 0.3 lux (visible)
LCD Screen
Size/Picture cell 2.5 inch/112k
Method TFT
Connectors
Video out Mini jack, 1 Vp-p, 75 ohms, Unbalanced
Audio out Mini jack, 7.7 dBs, imp.: less than 820 ohms
External mic Monaural ø3.5 (SCL906/L907)
General
Power requirement DC 8.4 V (1.5 A)
Power consumption 4.8 W
*Recording, LCD ON
Built-in mic Condenser mic, omni-directional
Built-in speaker Dynamic, 0.5 W standard
Operating temperature 0°C to 40°C (32°F to 104°F)
Dimension (WxHxD) 101x104x169 mm (3.98x4.09x6.65 inches)
Weight 790 g (1.47lbs)
