Camera setup
You can change the camera settings according to the environment where the camera is
located.
1. From the Setup menu, select the
<Video & Audio (
)> tab.
2. Click <Camera setup>.
3.
Configure the settings as necessary of :
Sensor, SSDR, White balance, Back
light, Exposure, Day/Night, Special, OSD
4. When done, click [Apply ( )].
`
If a certain time (timeout: 240s) is elapsed
with
your not pressing the [Apply (
)]
button after changing the settings, your
changes will not be applied.
To Set the Sensor
It specifies how many frames the camera CMOS sensor will capture per second.
1. Select <Sensor>.
2. Select <Mode>.
M
`
Refer to “Video profile” for the framerate
setup range of the <Video profile>
according to mode setup. (Page 70)
`
If the sensor mode is set to 50 fps or 60 fps, the <Back light> mode cannot be set to <WDR>.
English _77
● SETUP SCREEN
