Samsung WF455ARGSWR/AA Trouble Shooting Guide - Quick Test Mode Execution

ALIGNMENT AND ADJUSTMENTS
6
Model : WF455AR*
1. All LED’s light up and it sends out Beep
Sound when it enters into the Quick Test
Mode. (Including 7-Segment)
2 Displays software version for a sec and Clear
EEprom. (Ex. If S/W Version is 49, 7-Segment
will display Y349)
3. When the version is displayed, turn the
Jog-Dial. Press the following keys to test the
various components.
- Temp Key : Water Valve Test
- Spin Key : Door Lock/Unlock Test
- Soil Key : Water Heater Test
- Steam : Drain Pump / Bubble Pump /
Direct Valve Test
Model : WF457AR*
1. Displays software version for a sec and Clear
EEprom. (Ex. If S/W Version is 49, 7-Segment
will display Y349)
2. Press the following keys to test the various
components.
- No.1 Key : Water Valves Test
- No.2 Key : Door Lock/Unlock Test
- No.3 Key : Drain Pump / Bubble Pump /
Direct Valve Test
- No.4 Key : Water Heater Test
Quick Test Mode:
To avoid risk of electrical shock, personal injury or death; disconnect power to washer
before servicing, unless testing requires power.
WARNING
Quick Test Mode
S/W Version display
All LEDs On for 1 sec
(include 7-Segment)
All Devices Test using keys
Temp Key Soil Key SteamSpin Key
Quick Test Mode
S/W Version display
All Devices Test using keys
1 Key 3 Key 4 Key2 Key
