S&A CWFL-6000 - Specifications

CWFL-6000 Series
17
<8> Specifications
CWFL-6000
Model
CWFL-6000ET
Voltage
AC 3P 380V
Frequency
50 Hz
Current
3.4~15.7A
Compressor
power
4.95 KW
6.73 HP
Nominal
cooling
capacity
①
1706 Btu/h+47768 Btu/h
0.5 KW+14 KW
430 Kcal/h+12037 Kcal/h
Refrigerant
R-22 / R-407C
Refrigerant
charge
4400 g
Precision
±1℃
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power
0.75 KW+1.1 KW
Tank capacity
10 L+65 L
Inlet and outlet
Rp1/2”+ Rp1”
Max. lift
53 M+53 M
Max. flow
②
70 L/min+116 L/min
N.W
340 Kgs
G.W
435 Kgs
Dimension
147 X 70 X 149 cm (L X W X H)
Package
dimension
160 X 86 X 175 cm (L X W X H)
Note: ①the cooling capacity is under 30℃ water temperature and 40℃ ambient
temperature working conditions with standard voltage.
②The max. pump flow is obtained by testing the pump individually on test criteria
GB/T 3216-2005.criteria GB/T 3216-2005.
