S&A CWFL-6000 - Contour and parts introduction

CWFL-6000 Series
4
<2> Contour and parts introduction
TEMPERATURE CONTROLLER
POWER
ALARM AND
COMMUNICATION
OUTPUT
AIR OUTLET
AIR INLET
WATER SUPPLY INLET
WATER INLET
（
H
）
WATER OUTLET
（
H
）
WATER LEVEL GAUGE
WATER DRAIN
WASTE WATER DRAIN
OVERFALL GAP
WATER INLET
（
L
）
WATER OUTLET（L）
LOW TEMP PUMP
LOW PRESSURE
HIGH PRESSURE
POWER SWITCH
HIGH TEMP PUMP
CONDUCTIVITY METER
