Sandel SN3308 - 360 View with Map Illustration

A2-3
3
6
0
/
M
A
P
ILLUSTRATION 3 – 360 View with Map
Current NAV Source
(AUTO indicates GPS
in Auto-Sequence Mode)
Heading Bug
Selected Course
Current Waypoint,
Bearing & Distance
Bearing Pointer 2
Current A-B Memory
Current Heading
Groundspeed
Bearing Pointer 1
Source & Bearing
GPS Annunicators
Map Status Bar
Current Map Memory
Bearing Pointer 2 Source,
Distance & Bearing
CDI/Lateral Deviation
Bearing Pointer 1
Map Range
Selected Heading
Lubber Line
Flight Plan
Waypoints
Class C Airspace
Class B Airspace
Courseline
