Sandpiper HDF2 - Composite Repair Parts List

hdf2dl6sm-rev0316 Model HDF2 Page 11
ITEM PART NUMBER DESCRIPTION QTY.
1 031.012.000 SLEEVE & SPOOL SET 1
2 070.006.170 BEARING 2
3 095.043.010 BODY, AIR VALVE 1
095.043.156 BODY, AIR VALVE 1
4 095.073.001 PILOT VALVE ASSEMBLY 1
4-A 095.070.558 BODY, PILOT VALVE 1
4-B 560.033.360 O-RING 4
4-C 560.023.360 O-RING (SPOOL) 2
4-D 675.037.080 RETAINING RING 1
4-E 755.025.000 SLEEVE, PILOT VALVE 1
4-F 775.026.000 SPOOL, PILOT VALVE 1
5 114.002.010 INTERMEDIATE 1
114.002.156 INTERMEDIATE 1
6 115.158.080 BRACKET, LEG 2
7 115.159.080 BRACKET, LEG 2
8 132.002.360 BUMPER, DIAPHRAGM PLATE 2
9 132.014.358 BUMPER, AIR VALVE 2
10 135.016.162 BUSHING, THREADED, W/ O-RING 560.001.360 2
11 165.011.010 CAP, END 2
165.011.157 CAP, END 2
12 170.023.330 CAPSCREW, HEX HEAD (ALUMINUM ONLY) 8
12 170.023.330 CAPSCREW HEX HEAD
(CAST IRON AND STAINLESS STEEL) 16
13 170.024.330 CAPSCREW, HEX HD, 7/16-14 X 1 8
14 170.026.330 CAPSCREW, HEX HEAD 3/8-16 X 3 1/2 2
15 170.032.330 CAPSCREW, HEX HEAD 1/4-20 X 3/4 8
16 170.035.330 CAPSCREW, HEX HD, 7/16-14 X 1 1/2 (ALUMINUM ONLY) 8
17 170.045.330 CAPSCREW, HEX HEAD 5/16-18 X 1 1/4 4
18 170.052.330 CAPSCREW, HEX HEAD 3/8-16 X 2 1/2 2
19 170.061.330 CAPSCREW, HEX HEAD 3/8-16 X 2 16
20 171.002.110 CAPSCREW, SOCKET HEAD 2
171.002.330 CAPSCREW, SOCKET HEAD 2
21 196.001.010 CHAMBER, INNER 2
196.001.157 CHAMBER, INNER 2
22 196.002.010 NS CHAMBER, OUTER 2
196.002.110 NS CHAMBER, OUTER 2
196.002.157 NS CHAMBER, OUTER 2
23 286.007.354 DIAPHRAGM 2
286.007.356 DIAPHRAGM 2
286.007.360 DIAPHRAGM 2
286.007.363 DIAPHRAGM 2
286.007.364 DIAPHRAGM 2
286.007.365 DIAPHRAGM 2
286.007.366 DIAPHRAGM 2
24 312.012.010 ELBOW SUCTION 2
312.012.110 ELBOW SUCTION 2
312.012.156 ELBOW SUCTION 2
334.014.010 FLANGE, SUCTION (DUAL PORTED ONLY) 2
334.014.110 FLANGE, SUCTION (DUAL PORTED ONLY) 2
334.014.156 FLANGE, SUCTION (DUAL PORTED ONLY) 2
SERVICE AND OPERATING MANUAL
Model HDF2
Type 6
Heavy Duty Flap Valve
II 2GD T5
See pages 16 & 17
for ATEX ratings
