Sandpiper HDF2 User Manual

hdf2dl6sm-rev0316 Model HDF2 Page 2
Meanings of
Abbreviations:
A = Compressed Fibre DC = Die Cast PS = Plated Steel SS/I = Stainless Steel seat with EPDM O-Ring
AL = Aluminum H = Hytrel
®
S = Santoprene
®
T = PTFE
B = Nitrile I = EPDM SS = Stainless Steel U = Urethane
CI = Cast Iron N = Neoprene V = FKM (Fluorocarbon) F = FDA Accepted White Nitrile
Most types available in dual port design. See price book or consult factory for details.
Hytrel is a registered tradename of E.I. du Pont. Santoprene is a registered tradename of Exxon Mobil Corp.
‡
See CF-8M Materials information above.
Outer Inner Flap
Type Manifold Outer Inner Diaphragm Diaphragm Intermediate Diaphragm Valve Hard- Diaphragm Valve Sealing Shipping
Designation Elbow Chamber Chamber Plate Plate Housing Rod Seat ware Material Rings Wt. (lbs.)
DA6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS N U N 86
DB6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS B B B 86
DV6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS V V V 86
DN6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS N N N 86
DI6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS I I I 86
DP6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS/I PS S S I 86
DR6A. AL380DC AL380DC AL380DC PS PS 356-T6AL 416SS 316SS PS H H N 86
DA6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS N U N 133
DB6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS B B B 133
DV6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS V V V 133
DN6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS N N N 133
DI6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS I I I 133
DR6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS PS H H N 133
DP6I. CI CI AL380DC PS PS 356-T6AL 416SS 316SS/I PS S S I 133
DA6II. CI CI CI PS PS CI 416SS 316SS PS N U N 168
DB6II. CI CI CI PS PS CI 416SS 316SS PS B B B 168
DV6II. CI CI CI PS PS CI 416SS 316SS PS V V V 168
DN6II. CI CI CI PS PS CI 416SS 316SS PS N N N 168
DI6II. CI CI CI PS PS CI 416SS 316SS PS I I I 168
DP6II. CI CI CI PS PS CI 416SS 316SS/I PS S S I 168
DA6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS N U N 133
DB6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS B B B 133
DF6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS F F F 133
DV6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS V V V 133
DN6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS N N N 133
DI6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS I I I 133
DP6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS/I PS S S I 133
DR6S.
‡SS ‡SS AL380DC ‡SS PS 356-T6AL 416SS 316SS PS H H N 133
DA6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS PS N U N 168
DB6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS PS B B B 168
DV6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS PS V V V 168
DN6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS PS N N N 168
DI6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS PS I I I 168
DP6SI.
‡SS ‡SS CI ‡SS PS CI 416SS 316SS/I PS S S I 168
Explanation of Pump Nomenclature, HDF2
II 2GD T5
II 1 G c T5
II 1 D c T100
o
C
I M1 c
I M2 c
Models equipped with Cast Iron or Stainless Steel wetted
parts, and Cast Iron midsection parts.
II 2 G c T5
II 2 D c T100
o
C
All models, including pumps equipped with Aluminum
wetted and midsection parts.
II 2GD T5
MATERIALS OF CONSTRUCTION
To order a pump or replacement parts, rst enter the Model Number HDF2, followed by the Type Designation listed below in the far left column.
RECYCLING
Many components of SANDPIPER
®
AODD pumps are made
of recyclable materials (see chart on page 10 for material
specications). We encourage pump users to recycle worn out parts
and pumps whenever possible, after any hazardous pumped uids
are thoroughly ushed.
