Sandpiper S20 Operating Manual

s20mdl1sm-REV0708 Model S20 Metallic Page 25
Optional Muffl er Confi gurations, Drawing
OPTION 0
530-028-550 Integral Muffl er uses (1) Cap
and (4) 710-015-115 Self Tapping Screw to
hold it in place.
OPTION 1
530-027-000 Sound Dampening Muffl er
screws directly into the Air Valve body.
This muffl er is equipped with a porous
plastic element.
OPTION 2
530-010-000 Mesh Muffl er screws
directly into the Air Valve Body. This
muffl er is equipped with a metal element.
OPTION 6
530-033-000 Metal Muffl er screws
directly into the Air Body.
Option 1 and 2
Option 6
Option 0
ATEX Compliant
*
*
Note: Cannot be used with Air Valve
Assembly 031-179-000 used on
models equipped with cast iron or
stainless steel centers.
