Sandpiper SB1-A User Manual

sb1dl4sm-REV0108 Models SB1-A & SB25A Page 10
Composite Repair Parts List
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 031.039.000 Sleeve and Spool Set 1
2 050.008.354 Check Ball 4
050.008.356 Check Ball 4
050.008.360 Check Ball 4
050.008.363 Check Ball 4
050.008.365 Check Ball 4
050.011.600 Check Ball 4
3 070.012.170 Sleeeve Bearing 2
4 095.051.558 Valve Body 1
5 095.074.000 Pilot Valve Assembly 1
5A 095.071.551 Pilot Valve Body 1
5B 755.025.162 Pilot Valve Sleeve 1
5C 560.033.360 O-ring 4
5D 775.014.115 Pilot Valve Spool 1
5E 560.023.360 O-ring 4
5F 675.037.080 Retaining Ring 1
6 114.007.157 Intermediate Bracket 1
114.012.010 Intermediate Bracket (cast iron centers) 1
7 115.071.330 Mounting Bracket 1
115.070.330 Mounting Bracket (top ported only) 1
8 132.019.360 Bumper 2
9 132.022.360 Actuator Bumper 2
10 135.034.506 Bushing 2
11 165.038.356 End Cap 2
12 165.042.157 Valve Body Cap 1
165.042.558 Valve Body Cap (cast iron centers) 1
13 170.029.330 Hex Capscrew 16
14 170.032.330 Hex Capscrew 1/4-20 x 1.00 6
15 170.033.330 Hex Capscrew 3/8-16 x 3.25 4
16 170.045.330 Hex Capscrew 4
17 170.047.330 Hex Capscrew 6
18 170.063.115 Hex Capscrew 1
19 171.010.330 Flanged Capscrew 4
20 196.012.110 Outer Chamber 2
196.012.112 Outer Chamber 2
196.012.157 Outer Chamber 2
21 196.042.157 Inner Chamber 1
196.090.010 Inner Chamber (cast iron centers) 1
22 196.043.157 Inner Chamber 1
196.084.010 Inner Chamber (cast iron centers) 1
23 255.012.335 Pipe Coupling 3/4 NPT 1
24 286.008.354 Diaphragm 2
286.008.356 Diaphragm 2
286.008.360 Diaphragm 2
SERVICE AND OPERATING MANUAL
Model SB1-A/SB25A
CE
Type 4
II 2GD T5

Sandpiper SB1-A Specifications

General

Brand	Sandpiper
Model	SB1-A
Category	Water Pump
Language	English
