Sandpiper SB1-A User Manual

sb1dl4sm-REV0108 Models SB1-A & SB25A Page 13
1
Available in kit form. Order P/N 031-060-000 which also includes items 2, 13, 15, 31, & 45.
2
Available in kit form, Air End Kit 476-103-000.
Wet End Kits for SB1-A & SB25A:
Kit Number Pump Type
476-034-354
476-034-356 SR
476-034-360 SB
476-034-363 SV
476-034-365 SN
476-034-633 SC
476-034-634 SH
476-034-635 SGN
476-034-638 SGR
17 170.047.330 Hex Capscrew 3
25 334.013.110 Porting Flange 1" NPT 1
334.013.110 E Porting Flange 1" BSP Tapered 1
334.013.112 Porting Flange 1" NPT 1
334.013.112 E Porting Flange 1" BSP Tapered 1
334.013.157 Porting Flange 1" NPT 1
334.013.157 E Porting Flange 1" BSP Tapered 1
58 334.036.110 Dual Porting Flange 1" NPT 1
334.036.110 E Dual Porting Flange 1" BSP Tapered 1
334.036.112 Dual Porting Flange 1" NPT 1
334.036.112 E Dual Porting Flange 1" BSP Tapered 1
334.036.156 Dual Porting Flange 1" NPT 1
334.036.156 E Dual Porting Flange 1" BSP Tapered 1
59 170.121.330 Hex Capscrew 5/16-18 x 5.50 long 3
17 170.047.330 Hex Capscrew 3
58 334.036.110 Dual Porting Flange 1" NPT 2
334.036.110 E Dual Porting Flange 1" BSP Tapered 2
334.036.112 Dual Porting Flange 1" NPT 2
334.036.112 E Dual Porting Flange 1" BSP Tapered 2
334.036.156 Dual Porting Flange 1" NPT 2
334.036.156 E Dual Porting Flange 1" BSP Tapered 2
60 170.084.330 Hex Capscrew 5/16-18 x 7.00 long 3
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Dual Port Suction/Single Port Discharge
Dual Port Suction and Discharge
Composite Repair Parts List for

Sandpiper SB1-A Specifications

General

Brand	Sandpiper
Model	SB1-A
Category	Water Pump
Language	English
