SANLI LS 40 - Page 19



User’sManualSanliLS40/19
Type of machine Engine-powered lawnmower
Version Push
Cutting width 395 mm (15.5 in)
Engine Sanli 350 OHV single cylinder 4 stroke -
air cooled
Displacement 118 cc
Maximum power 2.3 kW (3hp) @ 4000 rpm
Maximum torque 5.4 Nm @ 3400 rpm
Rated speed 2900 rpm
Fuel type Unleaded premium petrol – 95 RON
Fuel tank capacity 1 litre
Ignition Electronic
Carburettor / throttle positions 4 positions, with starter
Starting system Manual
Engine oil 15W40 or SAE30
Engine oil capacity 650 ml
Type of air filter Foam
Forward speed --
Cutting height adjustment Individual wheels; 3 positions
Grass bag capacity 55 litres
Net Weight (empty) 24 kg
Spark plug type TORCH F6RTC
Spark plug gap 0.6 - 0.8 mm
Sound pressure measured at working
position
84.0 dB (A)
A
coustic power measured 92.5 dB (A)
Acoustic power guaranteed 94 dB (A)
Vibration AhW 3.8 m/s
2
Dimensions:(cms) a = 126, b = 102, c = 45, d = 77, e = 53



