6
Parts and functions
Front
Rear
AC power cord
S-VIDEO IN jack
COMPONENT IN jacks
*VOLUME
▲/▼
buttons
POWER button
*CHANNEL ▲/▼ buttons
Remote sensor
AUDIO (L/R)/VIDEO IN jacks (VIDEO2)
AUDIO (L/R)/VIDEO IN jacks
(VIDEO1)
* To display the menu screen.
Press both
VOLUME
▲/▼
buttons
at the same time to display the menu screen.
CHANNEL ▲/▼ buttons and
VOLUME
▲/▼
buttons can be used to select the desired setting during the menu
screen operations.
RF IN (VHF/UHF) jack
COAXIAL DIGITAL
AUDIO OUT jack
J3W50101A_En_p02-09 16/11/05, 9:12 AM6
