A2 Automatic Dispenser V3.0 10
Detailed steps as below:
1） Remove the connection pipe, lift the locking handle as figure to loosen the cleaning box.
2） Pull the cleaning box out as below figure.
3） Take the sponge brush and other parts out and clean them with water.
4） Put back of the sponge brush and other parts in proper order.
5） Put the cleaning box back, turn the locking handle to press the cleaning, install the water pipe.
2. Clean the cup
1） Remove the cup as figure
2） Pour out the sewage, clean the cup and refill
3） 80%-90% fresh water of the cup capacity.
4） Put the cup back and screw it down.
C. Cleaning of the type C built-in cleaning box.
The cleaning box is built-in. The daily maintenance and periodically maintenance shall be implemented
