Santon PowerPack - Internal Components; Safety

4
1.0 INTERNAL COMPONENTS
FIXING HOLES (3 NOS.)
TEMPERATURE
LIMITER 1
(ONE SHOT
OVER TEMP
CUT-OUT)
CABLE GRIP
DRAIN PLUG
DIFFERENTIAL PRESSURE
SWITCH ASSEMBLY
MAINS CONNECTOR BLOCK
WATER CONTAINER
ASSEMBLY
TEMPERATURE LIMITER 2
(OVER TEMP CUT-OUT)
Figure 2
NEON
Supplier’s name or trade mark Santon PowerPack
Supplier’s model identier 7kW 9kW
The declared load prole XXS XXS
The water heating energy efciency class of the model A A
The water heating energy efciency in % 38.5 38.5
The annual electricity consumption in kWh 479 479
Daily fuel consumption in kWh 2.206 2.206
Specic precautions that shall be taken when the water heater is
assembled, installed or maintained and disposed of at end of life
See sections 3 - 8
Table: Technical parameters in accordance with European Commision regulations 814/2013
and 812/2013
