Santos 27 - APPLIANCE TECHNICAL SPECIFICATIONS

98127 EN 2.2 - 12 2010 13 / 19 www.santos.fr
SANTOS : Instruction and maintenance manual
APPLIANCE TECHNICAL SPECIFICATIONS
Mains:
Power supply voltage
(V)
220-240 110-120 220-240
220-240
Three-
phase
380
Three-
phase
Frequency (Hz) 50 60 60 50 50
Start capacitor (µF) 150-190V 250-130V 150-190V
Motor
Rating (kW) 0,6 0,65 0,65 0,51 0,51
Motor speed (rpm) 1500 1800 1800 1500 1500
Number of speeds:
Min. planetary speed
(rpm)
50 60 60 50 50
Max. planetary speed
(rpm)
150 180 180 150 150
Min. tool speed (rpm) 180 210 210 180 180
Max. tool speed (rpm) 540 640 640 540 540
Noise: (2) L
pA
uncertainty K
pA
= 2.5dB
65 65 65 65 65
Dimensions and weight
Height (mm) 585
Width (mm) 340
Depth (mm) 570
Net weight (kg) 30
Packaged weight (kg) 34
Bowl Volume (l) 9,9
Useful volume (l) 8
(1) These ratings are given for your guidance. The exact electrical specifications of your appliance
can be found on the rating plate.
(2) Noise level measured in terms of acoustic pressure with the machine loaded according to
standards ISO 11201:1995 and ISO 4871:1996.
Appliance placed on a work surface 75cm above the ground. Microphone turned towards the
appliance at 1.6m from the ground and 1m from the appliance.
