Sanus BLF328 - Product Dimensions and Pre-Installation; Mount Dimensions and Specifications; Pre-Installation TV Setup

3
Dimensions
7.87in
200mm
MIN
7.87in
200mm
MIN
15.75in
400mm
MAX
23.62in
600mm
MAX
14.55in
369.6mm
2.36in
60mm
21.83in
554.6mm
16.00in
406.4mm
18.72in
475.6mm
11.57in
293.8mm
9.27in
235.4mm
24.00in
609.6mm
.36in
9.1mm
33.68in
855.6mm
33.80in
858.6mm
17.69in
449.3mm
.22in
[5.6mm]
OFFSET
2.15in
54.6mm
28.00in
711.2mm
5 deg
15 deg
UP
DOWN
9.08in
230.8mm
8.60in
218.6mm
C
L
TV INTERFACE
WALL PLATE TOP VIEW - EXTENDED
3-D
SIDE VIEW - EXTENDED
SIDE VIEW RETRACTED TOP VIEW - RETRACTED FULLY ASSEMBLED MOUNT
WALL IS ON RIGHTWALL IS ON RIGHT
57deg
WALL IS ON TOP
WALL IS ON TOP
57deg
SIMULATED 65"
FLAT SCREEN TV
TOP VIEW - EXTENDED
57deg
WA
57de
g
A
TED
65"
C
REEN T
V
BEFORE YOU BEGIN
Remove the stand
from your TV — if attached.
Install any accessories
you may have purchased, if they
require TV removal prior to assembly.
The TV is removable for future
accessory purchases.
Soft clean surface
Protect the face
of your TV when laying it
down for installation.
