Sanus BLF328 - Step 3: Attach TV to Wall Plate; Step 3 Parts and Hardware; Attach Arm Assembly to Wall Plate

10
WARNING: Before starting assembly, verify this part is undamaged. If damaged, do not return the damaged item to your dealer; contact
Customer Service. Never use damaged parts!
Attach TV to Wall Plate
STEP 3
3/32 in.
5/32 in.
10-32 x 3/8 in.
Parts and Hardware for STEP 3
Arm Assembly
LOCKING SCREWS
(ATTACHED)
CABLE COVERS
(ATTACHED)
CABLE
COVERS
(ATTACHED)
12
x1
11
x1
Securement
Screw
(ATTACHED)
C
C
14
x1
13
x1
Hex Key
Hex Key
08
1
HANG
08
11
11
For CONCRETE APPLICATIONS:
The arm assembly
11
MUST remain centered in wall plate
08
.
CAUTION:
Avoid potential personal injury or property damage!
3.1 Attach Arm Assembly to Wall Plate
HEAVY! You may need
assistance with this step.
2
SECURE
11
08
S
14
3
CLOSE COVERS
Always make sure both locking screws
S
are tightened, so the arm
assembly
11
is securely fastened to wall plate
08
.
CAUTION:
Avoid potential personal injury or property damage!
P
P
S
11
08
