Sanus BLF328 - Step 1 Continued: Mounting Brackets to TV; Measure TV Mounting Hole Pattern; Adjust Brackets for TV Width; Assemble Brackets Based on TV Height

5
1.3 Attach TV Brackets to Your TV
W
Adjust mounting tabs
M
on TV brackets
06
to match the width W
of your TV's mounting hole pattern.
400 mm position illustrated
2
ADJUST TO WIDTH W
Measure the WIDTH and HEIGHT of your TV's mounting hole pattern.
1
MEASURE
inch dimensions are approximate
W
H
06
M
M
inches cm mm
4 10 100
7 ⅞ 20 200
11 ¾ 30 300
15 ¾ 40 400
19 ¾ 50 500
23 ¾ 60 600
W
H
mm
mm
inches
cm
mm
4
10
100
For height 300 mm or less
For height greater than 300 mm
For hole pattern height H greater than 300 mm, align horizontal TV
brackets
06
with mounting tabs
M
to the outside.
For hole pattern height H 300 mm and less, align horizontal TV
brackets
06
with mounting tabs
M
to the inside.
3a
ASSEMBLE FOR HEIGHT H
3b
ASSEMBLE FOR HEIGHT H
≤ 300 mm
> 300 mm
04
04
06
06
06
06
M
M
