Sanus BSF316 - Drill Holes and Insert Anchors; Remove Wall Plate Covers

14
CAUTION:
Never drill into the mortar
between blocks.
2
DRILL
2X
CAUTION:
3/8 in.
(10 mm)
3 in. (7.5 cm)
Drill two pilot holes using a 3/8 in. (10 mm) drill bit.
IMPORTANT: Pilot holes must be drilled to a
depth of 3 in. (7.5 cm).
Remove wall plate covers
P
from arm assembly
06
.
4
REMOVE COVERS
06
P
P
14
3
2X
CAUTION:
Be sure the anchors
09
are seated
flush with the concrete surface.
CAUTION:
09
3
INSERT ANCHORS
Remove wall plate template
05
.
Insert two anchors
09
.
STEP 2B (continued)
