a: Flat Back
b: Round Back / Extra Space
Secure the assembly with the four
wing nuts
06
.
06
6
03
02
02
01
01
7
Center the TV bracket assembly
over your TV's hole pattern and attach using
screw combination
a
or
b
you selected for your TV.
CAUTION: Avoid potential personal injuries and property damage! DO NOT
use power tools for this step. Tighten the screws
01
only enough to secure the
TV brackets to the TV.
05
06
05
04
To Next Page
