16
HEAVY! You may need assistance with this step.
STEP 3 Hang TV onto Wall Plate
Lock TV to wall plate assembly
08
with screw
11
and washer
12
.
CAUTION! Avoid potential personal injuries and property
damage!Screw
11
must be installed to secure your TV onto
the wall plate assembly
08
.
Hang your TV onto the arm of wall plate assembly
08
by
first hooking the top support, then resting the TV into place.
1 2
08
04
11
12
To Next Page
