5
5/16 in.
5/16 x 2¾ in.
M5 x 8mm
M6/M8
2.5mm
22mm
M8 x 25mm M8 x 50mm
M6 x 12mm
M8 x 16mm
M6 x 35mmM6 x 20mm
M8 x 35mm
Supplied Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return
the damaged item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
STEP 1 Parts and Hardware
TV Screws
(qty. 4 each)
[Only one size fits your TV]
M6
M8
Washer
(qty. 4 each)
Spacers
[If necessary]
03
02
01
Vertical TV Bracket
Horizontal TV Bracket
Wing Nuts
M5
05
04
qty. 8
qty. 1
qty. 2
06
qty. 4
qty. 4
Shipped Attached
To Next Page
