Sanus LLF122 - TV Adjustments

18
TV Adjustments
TILT LEVEL
1. Loosen the tilt lever
T
.
2. Adjust the TV tilt position.
3. Tighten tilt lever
T
to secure the TV in place at your desired tilt angle.
NOTE: If needed, tighten screw
T2
for additional tilt tensioning.
T2
T
Tighten
Tighten
Loosen
Loosen
1. Loosen the screw
11
on the rear of wall
plate assembly
08
.
2. Level your TV.
3. Retighten screw
11
to secure in place.
Tighten
Loosen
13
08
08
11
