13
09
3 4
10
Drill pilot holes then remove the wall plate template
07
.
IMPORTANT: Be sure to drill into the center of the stud.
IMPORTANT: Pilot holes must be drilled to a depth of 2 ¾ in. (70 mm),
using a 7/32 in. (5.5 mm) diameter drill bit.
Install the wall plate
08
using four lag bolts
09
and washers
10
.
Tighten all lag bolts only until they are pulled firmly against the wall plate.
CAUTION: Improper use could reduce the holding power of the
lag bolt. DO NOT over-tighten the lag bolts.
Go to STEP 3 on PAGE 16.
07
08
7/32 in.
(5.5 mm)
2¾
in. (70 mm)
To Next Page
