• In the case of Ω/ , the modes change as:
Ω .
• In the case of µA, mA and A, the modes change as:
.
4-5 Range Hold
Press the RANGE button momentary to set the manual range
mode then 'AUTO' disappears in the display. In manual range
mode, press the button again to step through the ranges. To
return to the auto mode, press the button for 1 sec. or more then
AUTO is shown.
Note:
Manual mode is not available in Hz measurement.
4-6 Data Hold
When the HOLD button is pressed, the data display at that time is
hold (' ' is shown on the display). The display will not changed
while the function is active. Press the button again to cancel the
function. (' ' on the display disappears.)
4-7 Set Beeper Off
Press the Hz button while turning the function switch on to disable
the Beeper feature.
4-8 RS232C Interface
The instrument equips with an optical isolated interface port at the
meter back for data communication. Optional purchase KB-RS2
(RS232 cable) and PC Link or PC Link Plus (software) are
required for Data logging system. Refer to an instruction manual
in the PC Link or PC Link Plus for further details.
Note:
While data communication to PC, Capacitance readout can be
sent to PC correctly up to 500.0µF range because of low
response speed for large capacitance measurement.
—
7
—
