Power Supply:
Single alkaline 9V battery; NEDA1604, IEC6LF22 or 6LR61
Sensing:
AC, AC+DC True RMS
Auto Power Off Timing:
Idle for 17 minutes
Safety:
Meets the requirements for double insulation to EN61010-1 (1995),
UL3111-1 (6.1944), CSA C22.2 No.1010-1-92, IEC10101-1 to
terminals:
V/ /Ω• / /Hz : CAT for 600V DC & AC, and CAT for
1kV DC & AC
µA•mA : CAT 250V AC & 150V DC
A : CAT 500V AC & 300V DC
Transient Protection:
6.5kV (1.2/50µs surge)
E.M.C.:
Meets EN55022 (1994/A1; 1995/Class B) and EN50082-1
(1992)
Power Consumption:
2.6mA Typical
Dimension:
179(H) x 87(W) x 55(D) mm with holster
Weight:
320 mg, 460 mg with holster
Accessories:
Test leads (TL-82), Alligator clip (CL-13), Holster (H-50),
Battery (installed), Instruction manual
Optional Accessories:
RS232 cable: KB-RS2
Software: PC Link, PC Link Plus
Temperature Probe: T-300PC (Platinic thin film)
Clamp Probe: CL-20D, CL-22AD, and CL33DC
—
34
—
